Production line and factory setup overview
Produces PVC/ASA synthetic roofing tiles by controlled PVC/mineral compound mixing, co-extrusion or extrusion forming, profile calibration, cooling, cutting, optional ASA weather layer, inspection and packing.
Recommended lowest-entry line configuration Treat as medium industrial extrusion. Confirm formulation, UV/weather layer, profile geometry, impact/heat performance, overlap/fixing system and site temperature conditions before selecting equipment.
Production process and implementation sequence
- PVC/mineral compound batching
- Extrusion/co-extrusion
- Roof-profile forming and calibration
- Cooling and cut-to-length
- ASA/weather-layer verification
- Dimensional/performance inspection and packing
Products, capacity and market fit
- Approve a physical sample and installation system.
- Begin with selected sizes, profiles and finishes.
- Keep material and quality records for every batch.
- PVC/ASA synthetic roofing tiles - PVC/mineral formula, ASA weather layer, thickness, profile, UV/heat resistance, impact strength, overlap and fixing detail - Housing, warehouses, agricultural buildings, roofing contractors and building-material dealers
Core production machinery and line specifications
| Machine / stage | Function / value | Production note |
|---|---|---|
| Mixer/compound feeder | Controls PVC/mineral input | Approved formula |
| Extruder/co-extruder | Forms roofing sheet | Thickness/weather-layer target |
| Profile/calibration line | Sets roof geometry | Overlap/flatness check |
| Cooling/cutter/QC | Releases roof tile lengths | Dimension/impact check |
Raw materials, utilities and factory requirements
- PVC resin, calcium carbonate/mineral filler, stabilisers, pigments, ASA capstock/weather layer, additives and packaging
- Stable power, covered production/storage and reliable water where concrete is used
- Guarded cutting/forming equipment, documented maintenance and essential spares
Indicative low-entry investment and implementation plan
These planning ranges prioritize economical machinery, local labor and local civil works. Final pricing follows confirmed capacity, product specification, delivery terms and site conditions.
| Scope | Indicative range | Entry-plan note |
|---|---|---|
| Mixing, extrusion and profile line | US$300k–950k | Medium synthetic-roof process |
| Co-extrusion, cooling, cutting and QC | US$150k–450k | ASA/weather-performance scope |
| Indicative total | US$500k–1.4m | Building/resin inventory excluded |
Detailed proposal and next step
The proposal contains the complete line flow, machinery scope, raw-material and utility requirements, implementation stages and indicative entry planning. Final configuration follows confirmed products, capacity, site and budget.
