Production line and factory setup overview
A medium-industrial stone-finishing line converting sound calibrated marble or granite slabs and strip blanks into dimensionally accurate floor tiles through slab receiving and defect mapping, multi-blade strip cutting, cross cutting, face calibration, progressive grinding and polishing or honing, edge sizing and chamfering, washing and drying, dimensional and appearance grading, palletizing and protected packing. Block sawing is a separate upstream operation unless included.
Recommended lowest-entry line configuration Launch two standard tile sizes in one stone family and one finish. Screen a balanced line with slab/strip loading, one multi-blade strip cutter, one cross cutter, compact calibrating and 8-12 head tile-polishing line, edge calibrator/chamfer, wash-dry station, water recycling, gauges and A-frame/pallet handling. Prove slab yield and buyer tolerances before adding block sawing or many formats.
Production process and implementation sequence
- Slab receiving, rack inspection and defect mapping
- Multi-blade longitudinal strip cutting
- Cross cutting to tile length
- Face calibration to thickness
- Progressive grinding, honing or polishing
- Edge sizing and chamfering
- Washing, drying and dimensional grading
- Shade sorting, palletizing and protected packing
Products, capacity and market fit
- Afghan marble and granite gain more value as calibrated project-ready tiles than as rough slabs.
- Two standard sizes concentrate tooling, quality control, packing and inventory.
- A slab-input line avoids the much larger block-saw and quarry scope at launch.
- Repeatable thickness, squareness, shade grouping and surface finish are essential for contractor acceptance.
- Polished marble or granite floor tile - One stone family, two sizes, buyer-defined thickness, squareness, flatness, gloss, shade and edge limits - Flooring contractors, distributors and project exporters
- Honed floor tile - Approved matte finish, slip route and calibrated dimensions - Architectural interiors after sample approval
Core production machinery and line specifications
| Machine / stage | Function / value | Production note |
|---|---|---|
| Slab/strip loading tables and clamps | Handles stone safely without edge damage | Rated for launch slab size |
| Multi-blade strip cutter | Cuts parallel strips from slabs | Spacing for two tile sizes |
| Cross-cutting machine | Cuts strips into repeat tile lengths | Programmable stop or conveyor |
| Tile calibrating machine | Controls finished thickness and flatness | Stone-specific heads |
| Eight- to twelve-head polishing line | Develops honed or polished face | One finish at launch |
| Edge sizing and chamfering unit | Controls dimensions and protects edges | Buyer chamfer profile |
| Wash/dry and water-recovery system | Cleans tiles and recycles slurry water | Settling and filter press |
| Inspection, shade sorting and packing | Grades and protects saleable tiles | Master samples and calibrated gauges |
Raw materials, utilities and factory requirements
- Sound calibrated marble or granite slabs by variety and thickness
- Diamond blades, calibrating tools and stone-specific abrasive sequence
- Clean process makeup water and approved cleaning chemistry
- Pallets, separators, corner protection, cartons/crates, labels and machine spares
- Stable three-phase power with protected wet-area electricals
- Rated slab/tile lifting and non-marking conveyors
- Closed-loop cutting and polishing water with filter press
- Non-slip drained floors, splash barriers and good lighting
- Covered slab racks and finished-tile storage by shade lot
Indicative low-entry investment and implementation plan
These planning ranges prioritize economical machinery, local labor and local civil works. Final pricing follows confirmed capacity, product specification, delivery terms and site conditions.
| Scope | Indicative range | Entry-plan note |
|---|---|---|
| Strip and cross-cutting equipment | US$90k-240k | Two-size configured line |
| Calibration, polishing and edge finishing | US$140k-390k | Compact 8-12 head basis |
| Handling, inspection, water recovery and packing | US$55k-150k | Quality and environmental scope |
| Freight, civil interfaces, installation and spares | US$80k-220k | Wet-process erection |
| Indicative installed project total | US$365k-1.00m | Block saw, building, slabs and working capital excluded |
Detailed proposal and next step
The proposal contains the complete line flow, machinery scope, raw-material and utility requirements, implementation stages and indicative entry planning. Final configuration follows confirmed products, capacity, site and budget.
