Production line and factory setup overview
Builds rigid FRP production moulds from masters through plug finishing, release system preparation, gelcoat application, fibreglass/resin layup, controlled cure, frame reinforcement, trimming, polishing and trial-part inspection.
Recommended lowest-entry line configuration Use ventilated, controlled layup space and launch with a defined mould size. Confirm resin/gelcoat compatibility, glass schedule, cure, frame stiffness, surface class, release system and styrene/fire/worker-safety controls before scaling.
Production process and implementation sequence
- Plug/master finishing
- Release/sealer application
- Gelcoat spray/brush
- Fibreglass-resin layup
- Roller consolidation
- Curing/frame reinforcement
- Trim/polish
- Trial part/release-cycle check
Products, capacity and market fit
- Approve a physical sample and applicable standard.
- Launch with a defined product range and documented tool settings.
- Keep material and quality records for each batch.
- Fibreglass/FRP production moulds - Master surface class, gelcoat, resin system, fibreglass schedule, mould thickness, stiffening frame, cure, release system, surface polish and expected production cycles - Decorative panels, artificial stone, concrete/precast, boats, automotive trim, sanitaryware and composite workshops
Core production machinery and line specifications
| Machine / stage | Function / value | Production note |
|---|---|---|
| Plug finishing station | Prepares mould master | Surface class |
| Gelcoat/layup station | Builds face and laminate | Resin/glass schedule |
| Roller/consolidation tools | Removes voids | Air/laminate control |
| Curing/frame bench | Stiffens mould | Cure/frame rigidity |
| Polish/trial station | Releases production mould | Surface/demould test |
Raw materials, utilities and factory requirements
- Fibreglass mat/fabric, compatible resin, gelcoat, catalyst, release wax/PVA, core/frame materials, rollers, abrasive/polish materials and PPE
- Stable electricity, covered raw-material storage and protected finished-goods handling
- Guarded equipment, documented maintenance, essential spares and product-specific safety controls
Indicative low-entry investment and implementation plan
These planning ranges prioritize economical machinery, local labor and local civil works. Final pricing follows confirmed capacity, product specification, delivery terms and site conditions.
| Scope | Indicative range | Entry-plan note |
|---|---|---|
| Plug finishing and layup equipment | US$3k-12k | Small rigid mould workshop |
| Curing, trim, polish and ventilation | US$4k-18k | Resin safety/surface quality |
| Trial materials, PPE and setup | US$2k-8k | Mould-size dependent |
| Indicative entry total | US$9k-38k | Workshop and master-pattern cost excluded |
Detailed proposal and next step
The proposal contains the complete line flow, machinery scope, raw-material and utility requirements, implementation stages and indicative entry planning. Final configuration follows confirmed products, capacity, site and budget.
