Production line and factory setup overview
Creates CNC-carved wood, MDF or resin-sealed pattern masters for foundry work, concrete/gypsum moulds, decorative panels and prototypes through drawing preparation, nesting, CNC routing, hand finishing, sealing, measurement and protected packing.
Recommended lowest-entry line configuration Launch with small to medium pattern masters from stable MDF or selected timber for one buyer segment. Confirm final casting/mould material, shrinkage allowance, draft, machining tolerance, split lines, inserts, surface finish, sealant and repeat-use expectation before routing.
Production process and implementation sequence
- Target-machine and buyer-drawing review
- CAD/CAM and material/heat-treatment selection
- Cutting, machining, EDM or CNC routing
- Assembly, fitting and surface finishing
- Trial production with target material
- Measurement, functional checks and repeat-cycle inspection
- Packing, documentation and release
Products, capacity and market fit
- Tooling must be designed around the target production machine and released buyer drawing.
- First-off samples, measured dimensions and repeat-cycle evidence must be accepted before production release.
- Start with one high-demand product family and retain tool drawings, settings and maintenance records.
- CNC wood moulds and pattern masters - Buyer drawing, material and stability grade, shrinkage/draft allowance, split lines, insert locations, surface finish, sealant and repeat-use requirement - Foundries, precast/gypsum workshops, decorative-product makers, furniture firms and prototype buyers
Core production machinery and line specifications
| Machine / stage | Function / value | Production note |
|---|---|---|
| CAD/nesting station | Prepares routing and material layout | Allowance and grain/stability |
| CNC router | Carves pattern geometry | Working area and tolerance |
| Hand-finish bench | Refines details and assembly | Split/insert fit |
| Sealing/painting station | Protects the pattern surface | Moisture and release |
| Measurement/trial bench | Checks master against drawing | Dimensions and repeat use |
Raw materials, utilities and factory requirements
- Stable hardwood/MDF/PU board, sealers, release coatings, inserts, fasteners, router cutters, abrasives, measuring tools and packing
- Stable three-phase power, guarded machining, calibrated measuring tools, covered material/tool storage and safe lifting/handling
- Documented maintenance, critical wear spares, approved coolants/lubricants and product-specific safety controls
Indicative low-entry investment and implementation plan
These planning ranges prioritize economical machinery, local labor and local civil works. Final pricing follows confirmed capacity, product specification, delivery terms and site conditions.
| Scope | Indicative range | Entry-plan note |
|---|---|---|
| CAD/CAM workstation and CNC router | US$8k-30k | Small/medium work envelope |
| Dust extraction, finish bench and sealing | US$4k-16k | Surface and operator safety |
| Gauges, cutters and first materials | US$2k-9k | Pattern-specific setup |
| Indicative entry total | US$14k-55k | Building, large 5-axis router and working stock excluded |
Detailed proposal and next step
The proposal contains the complete line flow, machinery scope, raw-material and utility requirements, implementation stages and indicative entry planning. Final configuration follows confirmed products, capacity, site and budget.
