Production line and factory setup overview
Manufactures press dies and punches for ceramic floor or wall tiles through press-data review, tool-steel selection, CAD/CAM machining, heat treatment, grinding, punch assembly, powder-press trials and wear inspection.
Recommended lowest-entry line configuration Tool only for a named hydraulic press and tile format. Confirm press maker, table size, press force, cavity count, powder characteristics, tile thickness, edge/profile, punch hardness, clearance and required life before accepting an order.
Production process and implementation sequence
- Buyer drawing and machine-data review
- CAD/CAM and material selection
- Cutting, machining or casting of tool components
- Assembly, fitting and surface finishing
- Trial production with target material
- Dimensional, functional and repeat-cycle inspection
- Packing, documentation and release
Products, capacity and market fit
- Tooling is made only against an approved drawing and target production machine.
- Trial samples, dimensions and cycle-life evidence must be approved before final release.
- A small initial tool family keeps capital and spare-part complexity controlled.
- Ceramic tile press dies - Named press model, table/cavity size, tile format and thickness, punch and die material, clearance, surface finish, powder flow and cycle life - Ceramic tile factories, replacement-tool buyers and building-material producers
Core production machinery and line specifications
| Machine / stage | Function / value | Production note |
|---|---|---|
| CAD/CAM station | Matches die to press and tile format | Table/cavity geometry |
| CNC/EDM machining cell | Machines cavities and punches | Precision profile |
| Heat-treatment service | Hardens tool components | Specified hardness |
| Grinding/lapping bench | Sets clearance and finish | Parallelism |
| Press trial tooling | Validates formed green tile | Fill, release and edge quality |
Raw materials, utilities and factory requirements
- Tool steel, carbide or wear components where specified, springs, guides, fasteners, EDM/CNC consumables, heat-treatment service, gauges and packing
- Three-phase electricity, compressed air where required, guarded machining, covered tool storage and safe finished-tool handling
- Documented maintenance, critical wear spares, calibrated gauges and product-specific safety controls
Indicative low-entry investment and implementation plan
These planning ranges prioritize economical machinery, local labor and local civil works. Final pricing follows confirmed capacity, product specification, delivery terms and site conditions.
| Scope | Indicative range | Entry-plan note |
|---|---|---|
| CAD/CAM, CNC/EDM and die components | US$35k-140k | Press-specific precision tooling |
| Heat treatment, grinding and metrology | US$18k-80k | Hardness and clearance control |
| Trial, inventory and wear spares | US$10k-45k | One format family |
| Indicative entry total | US$63k-265k | Advanced machining workshop and tile press excluded |
Detailed proposal and next step
The proposal contains the complete line flow, machinery scope, raw-material and utility requirements, implementation stages and indicative entry planning. Final configuration follows confirmed products, capacity, site and budget.
