Production line and factory setup overview
A small/medium heat-treatment and converting line producing soft black binding wire from purchased hard-drawn low-carbon wire through coil receiving and chemistry/diameter inspection, controlled recoiling into furnace-compatible carriers, batch loading, oxygen-limited pot or bell annealing, programmed heating/soak/cooling, unloading and oxide inspection, tensile/elongation and bend testing, rewinding into merchant coils or cutting into tie bundles, weighing, packing and lot traceability. Drawing wire rod, pickling and galvanizing are separate upstream scopes.
Recommended lowest-entry line configuration For the lowest credible entry, buy hard-drawn SAE1006/1008-class wire at one diameter, typically 1.0-1.6 mm, and install one supported oxygen-limited batch pot/bell furnace with furnace carriers, controlled thermocouples and recorded recipes, plus recoiler, merchant-coil rewinder or straight-cut/bundle cell and tensile/elongation tools. Do not buy a complete 5.5-8 mm wire-rod drawing line until scale, descaling and several hundred kilowatts of power are justified.
Production process and implementation sequence
- Hard-drawn wire receiving and release
- Controlled recoiling onto furnace carriers
- Batch identification, loading and thermocouple placement
- Oxygen-limited heating and soak
- Controlled furnace cooling
- Unload, descale/clean only as specified
- Rewind coils or straighten/cut tie lengths
- Mechanical test, weight, pack and trace release
Products, capacity and market fit
- Construction crews need soft, consistent wire for tying reinforcement without brittle breaks.
- Buying hard-drawn wire avoids a high-power drawing/descaling line at entry.
- Batch annealing can serve one diameter while local demand and furnace utilization are proven.
- Annealing atmosphere, temperature uniformity and controlled cooling govern softness and scale.
- Black annealed binding-wire coil - One diameter, tensile-strength range, elongation, bend softness, coil mass, surface/scale and oil limits - Rebar contractors and building-material merchants
- Pre-cut tie-wire bundle - Same released wire cut to one buyer length with count/mass and safe ends - Construction crews seeking ready-to-use ties
Core production machinery and line specifications
| Machine / stage | Function / value | Production note |
|---|---|---|
| Input/recoiling machine and furnace carriers | Builds uniform furnace-compatible coils | One wire diameter |
| Batch pot or bell annealing furnace | Softens drawn wire under controlled atmosphere | Recorded heat/soak/cool cycle |
| Burner/electric controls and thermocouples | Controls temperature and atmosphere | Mapped furnace uniformity |
| Cooling and safe load-handling system | Prevents uncontrolled oxidation and burns | Rated carriers/lift |
| Merchant-coil rewinder or cut/bundle cell | Forms buyer packages | One launch format |
| Wire mechanical laboratory | Tests tensile, elongation, bend and wrap | Calibrated buyer method |
Raw materials, utilities and factory requirements
- Purchased hard-drawn low-carbon steel wire by chemistry and diameter
- Protective atmosphere or controlled combustion fuel as furnace design requires
- Coil ties, bags, labels and pallets
- Thermocouples, burner parts, bearings and rewinding spares
- Furnace fuel or high electrical load with engineered safety systems
- Three-phase power for handling and converting equipment
- Ventilated heat-resistant furnace bay and exclusion zone
- Rated coil lifting, carriers and protected cooling area
- Combustion/exhaust monitoring, fire protection and dry finished store
Indicative low-entry investment and implementation plan
These planning ranges prioritize economical machinery, local labor and local civil works. Final pricing follows confirmed capacity, product specification, delivery terms and site conditions.
| Scope | Indicative range | Entry-plan note |
|---|---|---|
| Recoiling, carriers and handling | US$10k-28k | Purchased drawn-wire route |
| Supported batch annealing furnace and controls | US$35k-95k | Capacity/fuel dependent |
| Rewinding/cutting, laboratory and packing | US$8k-24k | One product format |
| Exhaust, freight, installation and spares | US$12k-36k | Furnace safety scope |
| Indicative installed low-entry total | US$65k-183k | Wire-rod drawing, building and wire stock excluded |
Detailed proposal and next step
The proposal contains the complete line flow, machinery scope, raw-material and utility requirements, implementation stages and indicative entry planning. Final configuration follows confirmed products, capacity, site and budget.
